Grepow High Energy Density Battery Solutions for Commercial Drone

Grepow High Energy Density Battery Solutions for Commercial Drone

Editorial:Grepow Issue Date:2024-03-14 Views:347

Grepow's high energy density battery solutions are revolutionizing the capabilities of commercial drones, offering unmatched performance and reliability. These batteries are essential for powering the next generation of unmanned aerial vehicles (UAVs) used in various professional applications.


What Is High Energy Density Lithium Battery?

Energy density of a lithium battery refers to the amount of energy it can store per unit of weight or volume. It is typically measured in watt-hours per kilogram (Wh/kg). A higher energy density means the battery can store more energy in a smaller and lighter package. Usually, the energy density of lithium batteries can vary depending on the specific type and design. However, typical lithium-ion batteries used in consumer electronics have an energy density ranging from about 100 to 265 Wh/kg. Advanced lithium-ion batteries can have energy densities exceeding 320 Wh/kg. Lithium batteries with energy densities above 200 Wh/kg are generally considered to have a high energy density.

NMC Battery


Grepow High Energy Density Battery Solutions

Different lithium battery has different energy density. Since the polymer-based electrolyte used in LiPo batteries can be more conductive than the liquid electrolyte used in some Li-ion batteries, LiPo batteries generally have a slightly higher energy density compared to traditional Li-ion batteries. In LiPo batteries, the energy density of different types of LiPo batteries, such as LiCoO2, LiFePO4, LiMn2O4, NMC, etc., also varies. Grepow's High Energy Density Battery Solutions are NMC 811 batteries, with nickel, manganese, and cobalt accounting for 80%, 10%, and 10%, respectively. Grepow NMC 811 battery use stacked pouch cell technology, which has a high energy density up of to 280wh/Kg and can increase the battery endurance by 30% and cycle life more than of 500 (90% initial capacity). The following table shows the main product models of Grepow NMC 811 batteries. In addition, Grepow also provides customized High Energy Density battery services to meet the specific needs of various applications.

No.

Battery Type

Battery Model

Dimension(±5mm)

Weight(±100g)

1

NMC LIPO

Tattu NMC 811 5C 17000mAh 22.2V 6S1P

192x73x53mm

1532g

2

NMC LIPO

Tattu NMC 811 5C 20000mAh 22.2V 6S1P

189x76x58mm

1800g

3

NMC LIPO

Tattu NMC811 5C 22000mAh 22.2V 6S1P

192x78x68mm

1988g

4

NMC LIPO

Tattu NMC 811 5C 27000mAh 22.2V 6S1P

210x93x63mm

2440g

5

NMC LIPO

Tattu NMC 811 5C 28000mAh 222V 6S1P

204x92x65mm

2500g

6

NMC LIPO

Tattu NMC 811 5C 30000mAh 22.2V 6S1P

209x67x93mm

2580g

7

NMC LIPO

Tattu NMC 811 5C 17000mAh 44.4V 12S1P

200x111x73mm

2950g

8

NMC LIPO

Tattu NMC 811 5C 22000mAh 44.4V 12S1P

200x133x79mm

3850g

9

NMC LIPO

Tattu NMC 811 5C 20000mAh 44.4V 12S1P

200x122x78mm

3500g

10

NMC LIPO

Tattu NMC 811 5C 28000mAh 44.4V 12S1P

215x126x93mm

4800g

10

NMC LIPO

Tattu NMC 811 5C 30000mAh 44.4V 12S1P

213x132x93mm

4900g

11

NMC LIPO

30000mAh 44.4V 12S1P 5C

101*167*285.5mm

5880g

12

NMC LIPO

60000mAh 66.6V 18S2P 3C

183*242*254mm

15900g

Grepow NMC 811 Battery Is Ideal for Commercial Drone

Commercial drones are UAVs used for various professional applications. The main types include fixed-wing drones, multirotor drones (e.g., quadcopters, hexacopters), and hybrid drones. These drones require batteries with high energy density, discharge rates, and reliability for extended flight times and payloads. Grepow's NMC 811 battery is well-suited for commercial drones, offering long flight times and reliability. The following are the main types of commercial drones and their applications:

Agriculture:

◆Multirotor Drones: Used for crop monitoring, spraying, and mapping due to their versatility and ability to hover.

Fixed-Wing Drones: Ideal for large-scale crop monitoring and mapping, offering longer flight times and coverage.


Construction:

Multirotor Drones: Used for site surveys, progress tracking, and inspections, providing detailed imagery of structures.

Fixed-Wing Drones: Suitable for large construction sites, offering longer flight times and broader coverage for mapping and monitoring.


Film and Media:

Quadcopters: Commonly used for aerial photography and videography, providing stable and high-quality footage.


Mining:

Multirotor Drones: Used for site mapping, surveying, and monitoring, providing detailed 3D models of mining areas.

Fixed-Wing Drones: Ideal for large-scale surveys and mapping, covering extensive mining sites efficiently.


Oil and Gas:

Multirotor Drones: Used for pipeline and infrastructure inspections, providing detailed visual and thermal imaging.

Fixed-Wing Drones: Suitable for long-range inspections of pipelines and facilities in remote areas.


Public Safety:

Quadcopters: Commonly used for search and rescue missions, providing aerial support in locating missing persons or disaster survivors.

Fixed-Wing Drones: Used for wide-area surveillance and monitoring, offering longer flight times and broader coverage.


Real Estate:

Quadcopters: Ideal for capturing aerial views of properties for marketing purposes, providing high-quality imagery and videos.

Fixed-Wing Drones: Suitable for large properties or land surveys, offering longer flight times and broader coverage.


Telecommunications:

Multirotor Drones: Used for tower inspections, providing close-up views and detailed imaging of cell towers and antennas.

Fixed-Wing Drones: Suitable for large-scale inspections of telecommunication infrastructure, offering longer flight times and broader coverage.


Transport and Delivery:

Quadcopters: Used for parcel delivery in urban and remote areas, providing fast and efficient transportation of small packages.


Utilities:

Multirotor Drones: Used for infrastructure inspections, providing detailed visual and thermal imaging of power lines, wind turbines, and solar panels.

Fixed-Wing Drones: Suitable for large-scale inspections of utility infrastructure, offering longer flight times and broader coverage.


Conclusion

Grepow's NMC 811 batteries, with their high energy density and advanced technology, are ideal for commercial drones, offering long flight times, increased battery endurance, and exceptional cycle life. Whether used in agriculture, construction, film and media, mining, oil and gas, public safety, real estate, telecommunications, transport and delivery, or utilities, Grepow's batteries provide the power and reliability required for these demanding applications. With Grepow's customized High Energy Density NMC battery services, the possibilities for innovation in commercial drone technology are endless.
