Tracker / GPS

Global Positioning Systems (GPS) can provide accurate location data for all kinds of terrestrial and avian wildlife research and management projects. GPS tracking technology has been adopted in the management of movable assets. Tracking systems are normally powered by an individual battery: a rechargeable Lithium-Polymer battery. The battery type chosen for the product is dependent on the device's application environment.

GPS Battery Features

1. High safety performance: special enveloping technology to avoid potential internal short circuit.

2. Any special shape, according to your product application requirements.

3. Micro demension: 0.5~8 mm in thickness, 6~50 mm in width.

4. Support high rate discharge, fast charging capacity.

5. Wide operating temperature: -50 ℃~50 ℃ or -20 ℃~80 ℃.

6. Small & light: Small lithium batteries are compatible with all tiny dimension GPS tracking devices installed

in hidden or concealed places.

7. High energy density: Extended duration tracking requires large capacity batteries.

Grepow shaped batteries are designed with high energy density, which is smaller in size

but remain high capacity.

8. Custom, semi-custom, and off-the-shelf batteries.

9. Test samples will be completed in 7 days.

10. European and USA warehouse for easy supply.

Shaped Batteries
Button Cell Batteries

As GPS trackers are small and lightweight products, it becomes especially difficult to incorporate built-in GPS module, mobile communication module and battery at the same time. Therefore, in many cases, the preferred solution for GPS tracker power supply is micro-sized shaped rechargeable lithium-ion polymer batteries or rechargeable lithium-ion button batteries.

Shaped Batteries for GPS Trackers

There are not many manufacturers who can make shaped batteries and button batteries, Grepow independently developed and manufactured shaped batteries with stable working voltage, long cycle life, low power consumption, and various shapes and sizes; Grepow shaped batteries are widely used in various GPS trackers, including wildlife tracking, pet tracking, and property tracking.

In addition, our professional engineers can help you design, develop and manufacture customized GPS tracker power solutions to meet the specific needs of almost all applications, such as low temperature or fast charging, battery packs, BMS, etc.

Specs of Some GPS / Tracker Batteries

Model No.	Full Charged Voltage	C-Rate	Capacity	Internal Resistance	Weight(g)	Shape	Application
GRP5811047-S2A	4.2V	20C	200mAh	≤40mΩ	4.9±0.5	Rectangle	GPS Trackers
GRP3030027-G2A	4.2V	15C	140mAh	≤75mΩ	3.1±0.3	Round	GPS Trackers
GRP2524038-T1A	4.35V	10C	185mAh	≤80mΩ	4.1±0.5	Curved	GPS Trackers
