5" FPV Drone

5" FPV Drone

5-inch FPV drones are one of the most popular sizes among FPV enthusiasts and are commonly used for freestyle flying, racing, and aerial photography. They strike a balance between agility and stability, making them versatile for a wide range of flying styles and environments. A suitable battery for a 5-inch FPV drone is typically a high-rate lithium polymer battery with a capacity of around 1300mAh, available in 4S or 6S configurations.

Grepow FPV Drone Battery Features

High capacity retention rate

40C continuous discharge, the median voltage of ≥ 3.58V,

capacity retention rate >97%

Adopt advanced manufacturing process

Enhanced anti-drop performance by process improvement

 Long cycle life

35C discharge, cycle life >300 weeks

● Ultra-high discharge rate

Continuous discharge rate of 40C or more, instantaneous discharge rate of 150C or more

Support fast charging

5C fast charging, full charge only takes 25min

  • Battery for 5" Racing FPV Drone

  • Battery for 5" Freestyle FPV Drone

  • Battery for 5" Long Range FPV Drone

  • Battery for 5

    Some high-performance models may be compatible with 6S (22.2V) batteries for increased power. The capacity of the battery determines how long the drone can fly. For a 5-inch racing FPV drone, a battery with a capacity between 1300mAh to 1800mAh is commonly used. Higher capacities can provide longer flight times but will also be heavier. A higher C rating indicates the ability of the battery to deliver power quickly, which is important for racing drones. Look for a battery with a high C rating (e.g., 75C or higher) to ensure that it can handle the high current demands of the motors during aggressive maneuvers.

    Grepow Tattu 5" Racing FPV Drone Battery Solutions

    Battery Model

    Capacity

    Voltage

    Configuration

    C Rate

    Discharge Plug

    Package

    Size (L*W*H)

    Weight

    TA-RL3-120C-1300-6S1P

    1300mAh

    22.2V

    6S1P

    120C

    XT60

    Soft Pack

    78x39x39mm

    212g

    TA-RL3-120C-1400-6S1P

    1400mAh

    22.2V

    6S1P

    120C

    XT60

    Soft Pack

    78x39x49mm

    230g

    TA-RL3-120C-1550-6S1P

    1550mAh

    22.2V

    6S1P

    120C

    XT60

    Soft Pack

    77x39x48mm

    256g

    TA-RL4-130C-1050-6S1P

    1050mAh

    22.2V

    6S1P

    130C

    XT60

    Soft Pack

    78x40x34mm

    180g

    TA-RL4-130C-1300-6S1P

    1300mAh

    22.2V

    6S1P

    130C

    XT60

    Soft Pack

    78x39x38mm

    200g

    TA-RL4-130C-1400-6S1P

    1400mAh

    22.2V

    6S1P

    130C

    XT60

    Soft Pack

    78x39x42mm

    225g

    TA-RL4-130C-1550-6S1P

    1550mAh

    22.2V

    6S1P

    130C

    XT60

    Soft Pack

    76x38x44mm

    242g

    TA-RL5-150C-1200-6S1P-XT60

    1200mAh

    22.2V

    6S1P

    150C

    XT60

    Soft Pack

    78x39x35mm

    196g

    TA-RL5-150C-1400-6S1P-XT60

    1400mAh

    22.2V

    6S1P

    150C

    XT60

    Soft Pack

    78x38x40mm

    223g

    *Grepow offers customizable FPV drone battery solutions to meet the needs of various sizes and applications of FPV drones. Battery capacities range from 270mAh to 9000mAh, discharge rates range from 25C to 150C, and there are series options from 1S to 6S, as well as different discharge plugs, sizes, and packages. All batteries meet industry standards.

  • Battery for 5

    Like racing drones, 5-inch freestyle drones typically use 4S (14.8V) batteries for a good balance of power and weight. Some pilots may opt for 6S (22.2V) batteries for increased power and performance, but this may require additional tuning and could reduce flight time. For freestyle flying, a battery with a capacity between 1300mAh to 1800mAh is common. This provides a good balance between flight time and weight. Higher capacities can offer longer flight times but may impact agility

    Grepow Tattu 5" Freestyle FPV Drone Battery Solutions

    Battery Model

    Capacity

    Voltage

    Configuration

    C Rate

    Discharge Plug

    Package

    Size (L*W*H)

    Weight

    TA-FF13004SP

    1300mAh

    14.8V

    4S1P

    100C

    XT60

    Soft Pack

    73x35x28mm

    149g

    TA-FF15504SP

    1550mAh

    14.8V

    4S1P

    100C

    XT60

    Soft Pack

    71x35x35mm

    180g

    TA-FF-100C-1800-4S1P

    1800mAh

    14.8V

    4S1P

    100C

    XT60

    Soft Pack

    107x35x29mm

    206g

    TA-FF-100C-1300-6S1P

    1300mAh

    22.2V

    6S1P

    100C

    XT60

    Soft Pack

    75x36x44mm

    225g

    TA-FF-100C-1550-6S1P

    1550mAh

    22.2V

    6S1P

    100C

    XT60

    Soft Pack

    75x36x51mm

    260g

    TA-RL3-120C-1300-4S1P

    1300mAh

    14.8V

    4S1P

    120C

    XT60

    Soft Pack

    78x38x27mm

    148g

    TA-RL3-120C-1550-4S1P

    1550mAh

    14.8V

    4S1P

    120C

    XT60

    Soft Pack

    76x38x33mm

    176g

    TA-RL3-120C-1800-4S1P

    1800mAh

    14.8V

    4S1P

    120C

    XT60

    Soft Pack

    75x39x38mm

    199g

    TA-RL4-130C-1300-4S1P

    1300mAh

    14.8V

    4S1P

    130C

    XT60

    Soft Pack

    76x38x25mm

    143g

    TA-RL4-130C-1400-4S1P

    1400mAh

    14.8V

    4S1P

    130C

    XT60

    Soft Pack

    78x39x28mm158g

    Ta-RL4-130C-1550-4S1P

    1550mAh

    14.8V

    4S1P

    130C

    XT60

    Soft Pack

    76x38x30mm167g

    *Grepow offers customizable FPV drone battery solutions to meet the needs of various sizes and applications of FPV drones. Battery capacities range from 270mAh to 9000mAh, discharge rates range from 25C to 150C, and there are series options from 1S to 6S, as well as different discharge plugs, sizes, and packages. All batteries meet industry standards.

  • Battery for 5

    5-inch FPV drones used for long-range flights require a careful balance of capacity and weight to achieve optimal performance and endurance. These drones are typically equipped with high-efficiency motors and lightweight frames to maximize flight time and range. Grepow offers standard and customized 4S-6S high-rate lithium batteries tailored for the application of 5-inch long-range FPV drones. These batteries range in capacity from 550mAh to 1800mAh, providing options to suit different needs and flight durations. The high discharge rates, up to 130C, ensure that the batteries can deliver the required power for the drone's motors, enabling fast acceleration and stable flight performance.

    Grepow Tattu 5" Long Range FPV Drone Battery Solutions

    Battery Model

    Capacity

    Voltage

    Configuration

    C Rate

    Discharge Plug

    Package

    Size (L*W*H)

    Weight

    TA-75C-1050-4S1P-XT60

    1050mAh

    14.8V

    4S1P

    75C

    XT60

    Soft Pack

    71x36x26mm

    125g

    TA-75C-1800-4S1P-XT60

    1800mAh

    14.8V

    4S1P

    75C

    XT60

    Soft Pack

    106x36x25mm

    202g

    TA-RL-95C-850-4S1P-XT60

    850mAh

    14.8V

    4S1P

    95C

    XT90

    Soft Pack

    61x31x31mm

    105g

    TA-RL-95C-1050-4S1P

    1050mAh

    14.8V

    4S1P

    95C

    XT60

    Soft Pack

    72.5x35.5x24.5mm

    119.5g

    TA-RL-130C-1050-4S1P

    1050mAh

    14.8V

    4S1P

    130C

    XT60

    Soft Pack

    73x38x19mm

    128g

    TA-RL-95C-550-6S1P-XT30

    550mAh

    22.2V

    6S1P

    95C

    XT30

    Soft Pack

    63x19x42mm

    46g

    TA-RL-95C-650-6S1P-XT30

    650mAh

    22.2V

    6S1P

    95C

    XT30

    Soft Pack

    60x31x35mm

    115g

    TA-RL-95C-1050-6S1P

    1050mAh

    22.2V

    6S1P

    95C

    XT60

    Soft Pack

    75x36x37mm

    170g

    TA-RL3-120C-1050-6S1P

    1050mAh

    22.2V

    6S1P

    120C

    XT60

    Soft Pack

    76x40x37mm

    200g

    TA-RL4-130C-850-4S1P

    850mAh14.8V4S1P130CXT60Soft Pack58x29x30mm102g

    *Grepow offers customizable FPV drone battery solutions to meet the needs of various sizes and applications of FPV drones. Battery capacities range from 270mAh to 9000mAh, discharge rates range from 25C to 150C, and there are series options from 1S to 6S, as well as different discharge plugs, sizes, and packages. All batteries meet industry standards.
