Lokithor 12.8V LiFePO4 Powersports Starting Battery Solutions
The LOKITHOR LPS Series is a range of 12.8V LiFePO4 powersports starter batteries engineered for motorcycles, snowmobiles, ATVs, UTVs, personal watercraft, and scooters. Four models deliver 400A to 1500A of cranking power while combining low-temperature self-heating, Bluetooth and APP control, IP67 protection, and a weight reduction of more than 50% compared with conventional lead-acid batteries.
Model Number | LPS7-3 | LPS14-5 | LPS20-8 | LPS30-14 |
Battery Chemistry | LiFePO4 | |||
Battery Voltage | 12.8V | |||
Battery Capacity | 3Ah / 38.4Wh | 5Ah / 64Wh | 8Ah / 102.4Wh | 14Ah / 179.2Wh |
Cranking Amps | 400A | 600A | 900A | 1500A |
USB-C Input & Output | 5V-15V ⎓ 3A; 20V ⎓ 2.25A (PD 45W) | |||
SAE Charging Input | 14.5V / 3A | 14.5V / 5A | 14.5V / 8A | 14.5V / 10A |
Charging Temperature | -20°C to 60°C | |||
Operating Temperature | -40°C to 80°C | |||
Storage Temperature | -20°C to 50°C | |||
IP Rating | IP67 | |||
Dimensions (L x W x H) | 113 × 70 × 85mm | 149 × 87 × 93mm | 175 × 87 × 130mm | 166 × 127 × 176mm |
Net Weight | 700 ± 50g | 1100 ± 50g | 1660 ± 50g | 2800 ± 50g |
● Four 12.8V models provide 400A, 600A, 900A, or 1500A of cranking power for a broad range of powersports vehicles.
● LiFePO4 chemistry delivers stable output, strong thermal stability, and a long service life for dependable engine starts.
● Advanced lithium technology reduces battery weight by more than 50% while maintaining powerful starting performance, helping improve handling and simplify installation.
● A built-in low-voltage shutdown helps protect the battery during storage. Reactivate it through Bluetooth, the control-box button, or charging when power is needed.
● Integrated heating pads are precisely managed by the BMS to support reliable starting in cold conditions. The battery is designed for operation from -40C to 80°C.
● Bluetooth connectivity lets users view battery parameters and perform supported operations in the APP for convenient, intelligent battery management.
● The integrated BMS provides over-current, over-voltage, short-circuit, and temperature protection. An IP67-rated enclosure adds protection for demanding powersports environments.
The LPS Series is designed for motorcycles, snowmobiles, ATVs, UTVs, personal watercraft, scooters, and other 12V powersports vehicles. Select the appropriate model by checking the original battery size, terminal layout, required cranking performance, and the compatible lead-acid battery reference below.
LPS Model | Compatible Lead-Acid Battery References |
LPS7-3 | BTZ5S, BTZ7S, BTZ8V, BTX4L-BS, BTX5L-BS, BTX7L-BS, YTZ7S, YTZ8V, YTX4L-BS, YTZ5S-BS, YTX5L-BS, YTX7L-BS |
LPS14-5 | BT12A-BS, BTX12-BS, BTX14, BTX14B-4, BTX16-BS, BTX16-BS-1, BTX20CH-BS, BTZ10S, BTZ12S, BTZ14S, ETX12, ETX14, GYZ16H, HYB16A-AB, KMX14-BS, YT12A-BS, YTX7A-BS, YTX9, YTX9-BS, YTX12, YTX12-BS, YTX14, YTX14-BS, YTX14H, YTX14H-BS, YTX16-BS, YTX16-BS-1, YTX20CH, YTX20CH-BS, YTZ10S, YTZ12, YTZ12S, YTZ14, YTZ14S |
LPS20-8 | BTX15L, BTX15L-BS, BTX20L, BTX20L-BS, BTX20HL-BS, BTZ20L, ETX16L, ETX20L, GYZ20H, GYZ20L, GYZ20HL, Y50-N18L-A3, YB16CL-B, YB16HL-A-CX, YB16L-B, YIX20HL, YIX20HL-BS, YTX15, YTX15L, YTX15L-BS, YTX20, YTX20-BS, YTX20H, YTX20H-BS, YTX20L, YTX20L-BS, YTX20HL, YTX20HL-BS, YTX20HL-BS-PW, YTX20HL-PW |
LPS30-14 | BTX30L-BS, BTX30L, GYZ32HL, YTX30, YTX30L-BS, YIX30, YIX30L, YIX30L-BS, YIX30L-PW, YIX30L-BS-PW, ETX30L |
1. Correctly connect the control box red and black wires to the positive and negative battery terminals.
2. Connect the power adapter to the control box with a USB-C cable.
3. A breathing indicator light shows that charging is operating normally.
1. Correctly connect the control box red and black wires to the positive and negative battery terminals.
2. Press the control box button to wake the battery.
3. Connect the external device to the control box with a USB-C cable.
4. A solid indicator light shows that discharging is operating normally.
1. Correctly connect the control box red and black wires to the positive and negative battery terminals.
2. Connect the charger to the SAE port on the control box. The exposed end of the SAE connector is negative.
3. Check charging status through the charger indicator or the APP.
● Powersports Battery × 1
● Charging Control Box × 1 set
● Type-C Data Cable (USB-C to USB-C) × 1
● Phillips Screwdriver × 1
● Phillips Screws × 4
● Foam Padding (sufficient quantity)
● Warning Label × 1
● &User Manual × 1
Grepow provides end-to-end OEM/ODM support for global powersports brands, vehicle manufacturers, distributors, and aftermarket suppliers. From battery cells and BMS functions to mechanical design and branding, our engineering team can help turn specific application requirements into reliable, production-ready battery solutions.
● Electrical Customization: Tailor capacity, cranking performance, charging configuration, low-temperature heating, and BMS protection logic.
● Mechanical & Branding Support: Customize enclosure size, terminal configuration, labels, colors, packaging, and brand identity.
● Smart Feature Integration: Adapt Bluetooth communication, APP functions, parameter monitoring, and control-box interfaces to project needs.
● Scalable Manufacturing: Support prototype validation, sample builds, quality control, certification planning, and mass production.
Whether you are replacing an existing lead-acid battery or developing a new lightweight starter-battery platform, Grepow can provide a customized LiFePO4 powersports battery solution matched to your vehicle, market, and brand requirements. Contact us to discuss specifications, samples, and OEM/ODM options.
